MIL-PRF-85045/17C
Fluid immersion: Exposure to automobile gasoline and tap water are not required and the following test
temperatures shall be used for the fluids indicated: fuel oil (98 to 100 °C), turbine fuel (48 to 50 °C), and lubricating
oil (98 to 100 °C).
Chemical properties:
Halogen content: <0.2 percent
Cross-link verification: This test is applicable for cables with cross-linked jackets only. The test shall be
conducted in accordance with ICEA standard T-28-562 and run at 200 °C. The test shall be in the qualification test
sequence using a specimen cut from the sample used in the thermal shock test and in the Group III testing of the
Group C conformance test sequence. The hot creep elongation shall not exceed 100 percent, and the hot creep set
shall not exceed 10 percent.
Identification marking: For mixed fiber cables, the identification marking shall include the following:
8 Fiber 4 by 62.5/125, 4 by 9/125.
Part or identifying number (PIN) (see table I):
M85045/17-01P (Multimode)
M85045/17-02P (Single-mode)
"P" designates 7.7 Mpa hydrostatic pressure proof cable.
TABLE I. Supersession data.
PIN
Superseding
M85045/17-01P
M85045/13-01P
M85045/17-01
M85045/17-01N
M85045/17-01T
M85045/17-02P
M85045/13-02P
M85045/17-02
M85045/17-02N
M85045/17-02T
Qualification and conformance inspection: See table II.
TABLE II. Qualification and conformance inspection.
Cable length 1/
2/ 3/ 4/
Group
Qualification
Requirement
Test
Conformance
inspection
paragraph
paragraph
inspection
3 samples, 0.5 km each 5/
I
Visual and
3.4, 3.9, 3.10
4.7.2
A
mechanical
inspection
3 samples, 0.5 km each 6/
Attenuation rate
3.5.1
4.7.4.1
A
3 samples, 0.5 km each 6/
II
Crosstalk
3.5.3
4.7.4.3
--
1 specimen, 6 m 7/
Electromagnetic
3.7.16
4.7.6.16
--
effects
4
