MIL-PRF-85045/16C
TABLE I. Qualification and conformance inspection Continued.
Qualification
Requirement
Test
Conformance
Cable length 1/
2/ 3/ 4/
Group
inspection
paragraph
paragraph
inspection
1 specimen, 1 m 19/
VI
Acid gas generation
3.8.1
4.8.1
C
1 specimen, 1m 19/
Halogen content
3.8.2
4.8.2
--
1 specimen, 1 m 19/
Toxicity index
3.8.3
4.8.3
C
NOTES:
1/
Tolerance on 0.5-km length is ±5 percent, provided that results are normalized to 1 km.
2/
Tolerance on shorter lengths is ±5 percent.
3/
A sample is the initial 0.5-km cable length.
4/
A specimen is a cable length that is cut from the initial 0.5-km cable length (i.e., the sample) or is cut from a
longer previous cut length (i.e., cut from a longer specimen).
5/
The visual and mechanical inspection shall only be conducted on a 2-m section of each sample.
6/
The same samples as used in the visual and mechanical inspection shall be used.
7/
As stated under the applicable tests in this specification sheet.
8/
The same samples as used in the temperature cycling test shall be used.
9/
A specimen cut from each sample used in the temperature cycling test shall be used.
10/
Three specimens cut from each sample used in the temperature cycling test shall be used.
11/
A specimen cut from each specimen used in the temperature life test shall be used.
12/
The same specimen as used in the tensile loading and elongation test shall be used.
13/
A specimen cut from the specimen used in the thermal shock test shall be used.
14/
A specimen cut from the specimen used in the thermal shock test or one of the specimens used in the tensile
loading and elongation test shall be used.
15/
Specimens cut from the specimen used in the thermal shock test shall be used.
16/
Flat extruded jacket material strips (i.e., strips of flat extruded material with the same composition of the
cable jacket and of sufficient dimensions in which dumbbells can be cut) prepared as specified in 4.7.5.14
cited method and obtained from flat extruded material that underwent the thermal shock test shall be used.
17/
Flat extruded jacket material as specified in 4.7.5.15 shall be used in this test.
18/
Use 76-mm (3-inch) lengths of cable adjacent to one another to form a 76-mm (3-inch) strip. For a 2-mm
(0.08-inch) diameter cable, an approximate length of 3 m is needed.
19/
A specimen cut from one of the samples used in the temperature cycling test or specimen used in the thermal
shock test shall be used.
Qualification and conformance inspection by similarity:
Manufacturers who produce products for MIL-PRF-85045/17 or MIL-PRF-85045/18 and this specification
sheet, are qualified under MIL-PRF-85045/17 or MIL-PRF-85045/18, and whose product produced to this
specification sheet passes the tests and inspections specified in table II, are qualified under this specification sheet.
This qualification by similarity is applicable if the product produced to this specification was used in the production
of the already qualified product under MIL-PRF-85045/17 or MIL-PRF-85045/18. Testing may be performed on a
single length of cable, with a minimum length of 0.5 km.
5
